Angle measurers and inclinometers

GIM 60 Professional

Digital Inclinometer

Precise digital inclinometer

  • Measures precise tilts in degrees, percent or millimetres/metres
  • Direction arrows and audible signals at 0° and 90° for easy alignment
  • Measured values automatically turn on the display when working overhead
See technical details

Functions

Hold and Copy Hold/Copy function
Flip Display Rotating readout on display
Display lighting Illuminated display
IP protection 54 Dust and splash protection IP54
Measuring range of angles 0°-360° Angle measuring range 0°-360°

Your Selection

  • with 4 x battery (AA), Protective Bag
Show variant Buy from a Bosch partner Find a local dealer

with 4 x battery (AA), Protective Bag 0 601 076 700

GIM 60 Professional

Your Selection

with 4 x battery (AA), Protective Bag

Order number: 0 601 076 700

Buy from a Bosch partner Find a local dealer
Our service promise for professionals.
Extend the warranty of your power tools.
Register now!

Technical data

The most important data

Length 60
Measurement range 0 – 360° (4 x 90°)
Electronics measurement accuracy 0°/90° ± 0.05°
Electronics measuring accuracy at 1– 89° ± 0.2°
Measurement accuracy, vials ± 0.057° = ± 1 mm/m
Weight, approx. 0.77
Units of measurement °, %, mm/m
Tripod thread 1/4"
GIM 60
