Cordless Jigsaw
GST 18 V-LI S Professional

in cardboard box with anti-splinter guard

Powerful barrel grip jigsaw in the 18 V category

Choose product variation:

Print

The Professional 18V System.
Ultimate performance.
Maximum freedom.
Discover more!
More

Technical data

The most important data

Stroke rate at no load 550 – 2,700 spm
Stroke height 23 mm
Weight excl. battery 1.8 kg
Battery voltage 18 V
Packaging dimensions (width x length x height) 335 x 420 x 123 mm
Weight incl. battery 2.4 kg
Cutting depth
Cutting depth in wood 120 mm
Cutting depth in aluminium 20 mm
Cutting depth in unalloyed steel 8 mm
Noise/vibration information

Total vibration values (vector sum of three directions):

Sound pressure level 79 dB(A)
Sound power level 90 dB(A)
Uncertainty K 3 dB
Sawing wood
Vibration emission value ah 7.5 m/s²
Uncertainty K 1.5 m/s²
Sawing sheet metal
Vibration emission value ah 8 m/s²
Uncertainty K 1.5 m/s²

Advantages

Powerful barrel grip jigsaw in the 18 V category

  • Narrow barrel grip provides optimal control even when cutting from underneath
  • Tool-free Bosch SDS-system makes changing saw blades easy
  • Strong 18 V performance enables fast work progress

Functions

Battery 100 percent compatible with all tools within its voltage class Choose the XL battery for longest runtime or the compact battery for best handling
Metalworking The professional power tools for metalworking from Bosch.
Construction The professional power tools for construction from Bosch.
Woodworking The professional power tools for woodworking from Bosch.

Prices / Package contents


in cardboard box with anti-splinter guard

Order number: 0 601 5A5 100

Selected version

Price includes:

  • Hood 2 601 016 096
  • 1 x jigsaw blade T 308 B, Extra-clean for Wood (available separately as set of 3: 2 608 663 750)
  • 1 x jigsaw blade T 144 DP, Precision for Wood (available separately as set of 3: 2 608 633 A31)
  • 1 x jigsaw blade T 244 D, Speed for Wood (available separately as set of 3: 2 608 630 879)
  • Cardboard box
  • 1/1 L-BOXX inlay for tool and charger 1 600 A00 3NH

* Battery and charger not included


in L-BOXX with anti-splinter guard

Order number: 0 601 5A5 101

Price includes:

  • Hood 2 601 016 096
  • 1/1 L-BOXX inlay for tool and charger 1 600 A00 3NH
  • L-BOXX 136 1 600 A00 1RR
  • 1 x jigsaw blade T 308 B, Extra-clean for Wood (available separately as set of 3: 2 608 663 750)
  • 1 x jigsaw blade T 144 DP, Precision for Wood (available separately as set of 3: 2 608 633 A31)
  • 1 x jigsaw blade T 244 D, Speed for Wood (available separately as set of 3: 2 608 630 879)

* Battery and charger not included
